Camera IP Speed Dome PTZ, Wizmind, STARLIGHT, 4 MP, IR 500 M, 5.6-223 MM, 40X, auto- tracking, recunoastere faciala, SMD, metadata, slot card, HI-POE - SD8A3440GA-HNV

Camera IP Speed Dome PTZ, Wizmind, STARLIGHT, 4 MP, IR 500 M, 5.6-223 MM, 40X, auto- tracking, recunoastere faciala, SMD, metadata, slot card, HI-POE
Senzor 1/1.8 inch progresiv CMOS STARVIS
Rezolutie maxima 4 Megapixeli (2560 x 1440 pixeli)
Viteza shutter electronic 1/1 s-1/30,000 s
Sensibilitate Culoare: 0.001 lux@F1.6
B/W: 0.0001 lux@F1.6
0 lux (IR pornit)
Distanta iluminare IR 500 m
Numar LED-uri IR 10
Control on/off iluminator Zoom Prio; Manual; Auto; Off
Lentila varifocala 5.6 - 223 mm
Diafragma F1.6-F4.9
Unghi de vizualizare H: 63.9°-2.1°; V: 37.3°-1.2°; D: 71.2°-2.4°
Zoom optic 40×
Zoom digital 16x
Control focus Auto; Semi-auto; Manual
Control Pan/Tilt Pan: 0° to 360°
Tilt: -30° to +90°, auto flip 180°
Viteza control manual Pan: 0.1°-240°/s
Tilt: 0.1°-100°/s
Viteza preset Pan: 240°/s; Tilt: 100°/s
Numar Preset-uri 300
Pattern 5
Scan 5
Memorie power-off Da
Tur 8 (pana la 32 presets per tur)
Alarma I/O 7/2
Audio I/O 1/1
RS-485 1

IVS (Protectie perimetrala) Tripwire si intruziune. Suport declansare alarma prin tipuri de tinte (uman si vehicul). Suporta filtrarea alarmelor false cauzate de animale, frunze, surse de lumina puternica etc.
Functii auto-tracking, Hi-PoE, detectie faciala, tehnologia Starlight, Video Metadata, protectie perimetrala, SMD
Video
Compresie video Smart H.265+;H.265;Smart H.264+;H.264;H.264B; H.264H;MJPEG(Sub Stream)
Zi/Noapte Color; B/W; Auto; Electronic
Functii speciale BLC, WDR 120 dB, EIS, 3D/2D DNR, Detectie miscare, Defog electronic, HLC
Balans alb Auto; indoor; outdoor; tracking; manual; sodium lamp; natural light; street lamp
Control gain Auto; Manual
Regiune interes Da
Control biti CBR; VBR
Rotire imagine 180°
Zone private Pana la 24 de zone pot fi setate, cu pana la 8 zone in aceeasi vizualizare
Port retea RJ-45 (10/100 Base-T)
Numar utilizatori 20 (latime de banda totala: 64 MB)
Telefoane compatibile iOS; Android
Alimentare 36V DC, 2.23 A (± 25%)
Consum de energie Baza: 17 W; Max.: 30 W (iluminator + PTZ)
Temperatura de functionare -40 pana la +70 °C
Umiditate de functionare ≤ 95%
Protectie IP67; IK10; TVS 8000 V rezistent la trasnet; protectie la supratensiune; protectie la tranzitorii de tensiune
Dimensiuni 415.9 × Φ262 mm
